Item

    Name

Unit

Data

Remark

1

Max bending capacity

mm

○

Φ25×1.5mm

□

Φ18 X 18 X 1.5mm

●

12

2

Max bending radius

mm

100

or customer’s requirement

3.

Min bending radius

mm

Depend on the pipe diameter

4

Max feeding length

mm

2500

Or customer’s requirement

5

Max bending degree

Degree

190

6

Control Panel

PLC +touch screen

7

Bending unit

 piece

16

8

Working speed

bending speed

Deg/sec

150

Rotary speed

Deg/sec

200

Feeding speed

mm/sec

1000

9

Accuracy

feeding

mm

±0.1

rotary

Degree

±0.1

bending

Degree

±0.1

10

Rotary servo motor power

W

750

Japan Mitsubishi

11

Feeding servo motor power

Kw

1

Japan Mitsubishi

16

The accuracy of roller

mm

Max 50

Or customer’s requirement

17

Oil motor power

Kw

4

18

Max storage units

group

1000

Or as requirement

19

Max pressure

MPa

12

Adjustable

20

Hydraulic control system

Magnetic exchange valve

Japan Yuken

21

Oil tank

L

110

22

Oil cooler

L/Min

150

23

Machine weight

Kg

1500

24

Machine size

mm

3100 ×720×1230

25.

Working height

mm

1300

26

Delivery time

days

50 days

27

Warranty time

month

12
