Item

Name

Unit

Data

Remark

1

Max bending capacity

○

Φ50×3mm

□

35 X 35 X 2mm

2

Max bending radius

mm

250

Can according to customer’s requirement

3

Min bending radius

mm

Depend on diameter

4

Max feeding length

Mandrel length

mm

3000

Can according to customer’s requirement

5

Max bending degree

Degree

190

6

Control Panel

PLC+touch screen

7

Bending unit

piece

16

8

Working speed

bending speed

Deg/sec

85

Rotary speed

Deg/sec

200

Feeding speed

mm/sec

1000

9

Accuracy

feeding

mm

±0.1

rotary

Degree

±0.1

bending

Degree

±0.1

10

Rotary servo motor power

W

750

Japan Mitsubishi

11

Feeding servo motor power

Kw

1

Japan Mitsubishi

12

The accuracy of roller

mm

Max 70

customized

13

Oil motor power

Kw

5.5

14

Max storage units

group

2000000

customized

15

Max pressure

MPa

12

Adjustable

16

Hydraulic control system

Magnetic exchange valve

Japan Yuken

17

Oil tank

L

190

18

Machine weight

KG

2500

19

Machine Size

mm

5000*1300*1500
