Item

    Name

Unit

Data

Remark

1

Max bending capacity

mm

Ordinary Steel

Φ75×3t

Stainless steel

Φ70×3t

Square steel

50.8 X 50.8 x 2

2

Max bending radius

Bending radius by winding

Round pipe

mm

1.5 x OD – 5 X OD

Or according to customer’s requirement

Rectangle pipe

1.5 X OD – 5 X OD

Bending radius by pushing

Round pipe

6 X OD -∞

Rectangle pipe

6 X OD -∞

3

Max feeding length

mm

3000

4

Max bending degree

Degree

190

5

Control Panel

PLC +touch screen

6

Accuracy

feeding

mm

±0.1

rotary

Degree

±0.1

bending

Degree

±0.1

7

Rotary servo motor power

kW

1

Mitsubishi

8

Feeding servo motor power

Kw

7

Mitsubishi

9

Rolling servo motor power

Kw

11

Mitsubishi

10

Oil motor power

Kw

6

11

Oil cooler

L/Min

150

12

Machine weight

Kg

5500

13

Machine size

mm

5500×1500×1750
