Item

    Name

Unit

Data

Remark

1

 Max bending capacity

mm

Φ100 ×8t

● 50mm bar

□ 70 x 70 mm

2

Bending Torque

N.M

10000

4

Max bending radius

mm

500mm

5

Min bending radius

mm

50mm

5

Max feeding length

mm

3600mm

Can according to customer’s requirement

7

Max bending degree

Degree

190

8

Bending Speed

10°/s

9

Bending accuracy

degree

± 0.2

10

Control system

       NC control

11

Max bending unit on the same pipe

unit

16

12

Max storage sections

unit

16 x 16

13

Main Motor Power

Kw

15

14

Oil tank

L

300

15

System hydraulic pressure

Mpa

14

16

Machine Size

mm

5000 x 1600 x 1200

17

Machine Weight

KGS

5000
